RESILIENT ISOLATION · STUD DECOUPLING

Wall & CeilingIsolationClips

Vibration Control / Structure-Borne Noise

Used for Vibration control · structure-borne noise reduction

Installation area Wall studs / ceiling joists

Main metric Vibration isolation efficiency · IIC (for floors)

Important: This product reduces vibration and structure-borne noise from mechanical systems and impacts. It does not absorb echo or block airborne sound on its own.

Resilient clips with a rubber decoupler insert mount to the stud or joist and hold a hat-channel that carries the drywall — the drywall never touches the structure. Result: +12 to +18 dB STC with no extra wall thickness.

Request a Quote → See Specs

Yamamah Smart wall and ceiling isolation clips — three vibration-decoupling products in stock: hat-channel clip, neoprene pad with stud, and rubber-isolated machine mount

+12 to +18 dB STCRUBBER DECOUPLEDSTUD + JOIST MOUNTHAT CHANNEL COMPATIBLEFIRE A1 STEELFAST INSTALLANY DRYWALL+12 to +18 dB STCRUBBER DECOUPLEDSTUD + JOIST MOUNTHAT CHANNEL COMPATIBLEFIRE A1 STEELFAST INSTALLANY DRYWALL

+12 to +18 dBSTC GAIN
30 KGPER CLIP
30 mmADDED DEPTH
A1FIRE CLASS

ABOUT

What Are Resilient Isolation Clips?

A small metal cradle screwed to your stud or ceiling joist, with a rubber pad that the drywall channel rests on. The rubber breaks the rigid connection that normally carries impact and low-frequency airborne noise. Used in recording studios, apartments, home theatres, hospitals and offices wherever a wall or ceiling needs to actually block sound.

Mount Clip

Steel clip screws to the stud — rubber decoupler isolates the metal.

Snap Channel

Hat-channel snaps into the clip — carries the drywall horizontally.

Decouple

Drywall never touches the stud. +12 to +18 dB STC, no extra wall thickness.

APPLICATIONS

Apartments & HotelsBlock neighbour footfall, TVs, voices through party walls and ceilings.
Recording StudiosDecouple control room from live room — essential for low-frequency isolation.
Home TheatresStop sub-bass leaking into adjacent rooms or upstairs bedrooms.
HospitalsPatient privacy and quiet zones (ICU, NICU, consulting rooms).
Offices & BoardroomsConfidentiality between meeting rooms without doubling wall thickness.
SchoolsClassroom-to-classroom and corridor-to-classroom isolation.

TECHNICAL SPECS

Material (clip body)Galvanized steel 1.5 mm

DecouplerEPDM / Neoprene rubber

Static load capacity30 – 35 kg per clip

STC improvement+12 to +18 dB (system dependent)

Stud spacing supported400 mm / 600 mm

Channel compatibility25 mm and 38 mm hat channel

Fire class (steel)A1 (non-combustible)

Fire class (rubber)Self-extinguishing

Operating temp-20 °C to +80 °C

OriginImported · stocked in KSA

WHY CHOOSE THIS

Why Choose Resilient Clips

Massive STC gain

+12 to +18 dB on a standard 2× drywall build — equivalent to doubling wall mass.

No extra thickness

Total system adds ~30 mm — keeps your room volume intact.

Quiet at low frequencies

Rubber decoupler kills the 60–250 Hz band where most neighbour noise lives.

Fast install

Same trades as standard drywall — no specialist labour needed.

FAQ

Frequently Asked Questions

How many clips do I need per square meter?

Typical layout uses one clip every 600 mm horizontally on a 600 mm stud spacing — that's about 4 clips per m². Add 25% for ceilings or heavy double-drywall systems.

Can I use them on a ceiling?

Yes. For ceilings always check the static load — a double-drywall ceiling system loads each clip with 12–18 kg, well within the 30 kg rating.

Do they work with green glue or damped drywall?

Yes — clips and viscoelastic damping compounds are complementary. Clips handle decoupling, damping compounds handle resonance. Used together they can push STC into the mid-60s.

Are they fire rated?

The steel body is non-combustible (A1). The rubber insert is self-extinguishing. Used in any standard partition that meets local fire code.

What's the lead time?

Stock items in Riyadh, Jeddah and Dammam ship within 48 hours. Bulk project orders (10,000+ clips) lead time 3–5 weeks.
