NeopreneAnti-VibrationPads

Vibration Control / Structure-Borne Noise

Used for Vibration control · structure-borne noise reduction

Installation area Under machinery / equipment

Main metric Vibration isolation efficiency · IIC (for floors)

Important: This product reduces vibration and structure-borne noise from mechanical systems and impacts. It does not absorb echo or block airborne sound on its own.

Ribbed and waffle-pattern neoprene rubber pads placed under HVAC chillers, pumps, gensets, transformers and any rotating equipment — cuts vibration transmission to the structure by up to 95%, eliminates structure-borne hum, and prevents fastener loosening.

Request a Quote → Sizes & Specs

Yamamah Smart neoprene anti-vibration pads — actual ribbed rubber pads ready for installation under HVAC, pumps and generators

UP TO 95% VIBRATION CUTRIBBED + WAFFLEFIRE RATEDOIL RESISTANT-30°C to +90°CDURO 60 SHORE ACUSTOM SIZESUP TO 95% VIBRATION CUTRIBBED + WAFFLEFIRE RATEDOIL RESISTANT-30°C to +90°CDURO 60 SHORE ACUSTOM SIZES

UP TO 95%VIBRATION CUT
0.5 N/mm²MAX LOAD
60SHORE A
KSAIN STOCK

ABOUT

What Are Neoprene Pads?

Engineered rubber pads (typically 8–25 mm thick) with a ribbed or waffle face. The pattern creates micro air pockets that compress under load, absorbing vibration before it reaches the slab. Used under any rotating or oscillating equipment — from a small split-AC outdoor unit to a 5-ton chiller. Easy to cut to size with a sharp knife.

Place

Position the pad under each equipment foot — no glue, no tools.

Compress

Equipment weight compresses the ribbed top + waffle core.

Isolate

Vibration is absorbed in air pockets — never reaches the slab.

APPLICATIONS

HVAC UnitsSplit AC outdoor units, FCUs, AHUs, VRF condensers.
PumpsWater booster pumps, transfer pumps, chilled water pumps.
GeneratorsStandby and prime gensets up to 500 kVA.
TransformersMV/LV distribution transformers (dry and oil type).
CompressorsAir compressors, refrigeration compressors.
Studio RacksServer racks, audio racks, transformer cabinets.

TECHNICAL SPECS

Material100% neoprene rubber

Hardness60 ± 5 Shore A

Thickness8, 10, 15, 20, 25 mm

Standard pad sizes100×100, 150×150, 200×200, 300×300 mm

PatternRibbed top + waffle bottom (dual)

Density1.25 g/cm³

Static load (15 mm pad)Up to 0.5 N/mm² (500 kPa)

Vibration reductionUp to 95% (load-tuned)

Operating temp-30 °C to +90 °C

Fire classSelf-extinguishing

Oil resistanceGood (better than EPDM / natural rubber)

OriginImported · stocked in KSA

WHY CHOOSE THIS

Why Neoprene Pads

No power tools

Cut with a knife, place under the equipment foot — done. No drilling.

Engineered patterns

Ribbed + waffle dual face spreads load and grips both equipment and slab.

Long life

10+ years outdoors; doesn't UV-crack or harden like cheaper EPDM.

Stackable

Need more isolation? Stack 2 or 3 pads with a steel plate between to tune the natural frequency.

FAQ

Frequently Asked Questions

How thick a pad do I need?

Rule of thumb: 10 mm under loads <100 kg per foot, 15 mm under 100–300 kg, 20–25 mm under heavier. For critical low-frequency isolation we use spring isolators instead.

Can I just cut a generic rubber sheet?

You can, but you lose the pattern. The ribbed-waffle dual face is what spreads load and prevents micro-slip — that's the whole point. Generic flat rubber is 20–30% less effective and squeezes out from under heavy loads.

Do they need glue?

No. Friction holds them in place under load. For wind-exposed outdoor units we sometimes recommend a single dab of polyurethane sealant at one corner — never full glue (kills the isolation).

Are they oil resistant?

Yes — neoprene resists oils, fuels and most industrial chemicals far better than EPDM or natural rubber. Safe under gensets and hydraulic pumps.

Custom sizes available?

Yes. We can supply rolls (1 m × 5 m) for site-cut, or pre-cut custom shapes for project orders.
