CEILING SUSPENSION · SPRING ISOLATION

SuspensionKit

Vibration Control / Structure-Borne Noise

Used for Vibration control · structure-borne noise reduction

Installation area Ceiling suspended systems

Main metric Vibration isolation efficiency · IIC (for floors)

Important: This product reduces vibration and structure-borne noise from mechanical systems and impacts. It does not absorb echo or block airborne sound on its own.

Ceiling suspension hardware that lets you hang acoustic baffles, clouds, ducts and signage with spring vibration isolators, anchor plates, eye-bolts, steel cable and adjustable grippers. Every part decouples the suspended element from the structure — no structure-borne hum.

Request a Quote → Kit Contents

Yamamah Smart suspension kit — acoustic ceiling cloud suspended by four steel-cable hangers with adjustable grippers

SPRING ISOLATED30 kg / 60 kg / 100 kg KITSADJUSTABLE LENGTH1.5 mm STEEL CABLEFIRE A1FAST INSTALLSPRING ISOLATED30 kg / 60 kg / 100 kg KITSADJUSTABLE LENGTH1.5 mm STEEL CABLEFIRE A1FAST INSTALL

UP TO 100 KGPER POINT
8–12 HzNAT. FREQ.
0.5–3 mADJUSTABLE
A1FIRE CLASS

ABOUT

What's in a Suspension Kit?

A complete kit for one suspension point: anchor plate, eye-bolt, steel cable, spring vibration isolator, gripper-lock adjuster, and the lower attachment hardware. Pick a kit rated for your load (30, 60 or 100 kg per point) and use one kit per attachment. Used to hang acoustic baffles, ceiling clouds, ducting, lighting fixtures, signage and projectors.

Anchor

Anchor plate + eye-bolt screwed into the slab; cable hangs below.

Isolate

Spring isolator inline with the cable decouples vibration from the slab.

Adjust & Hang

Gripper-lock adjuster sets exact height — baffle hangs free, zero structure-borne hum.

APPLICATIONS

Acoustic BafflesHang vertical fabric or felt baffles in open-plan offices, schools and lobbies.
Ceiling CloudsSuspend horizontal absorbent panels at a defined height under hard ceilings.
HVAC DuctingDecouple ducts from the slab — eliminates the most common structure-borne hum source.
Lighting FixturesPendant lights, signage and decorative installations that need vibration isolation.
Projector / AVVibration-free projector mounts in studios and conference rooms.
Audio SpeakersHanging studio monitors decoupled from the structure.

TECHNICAL SPECS

Static load options30 kg / 60 kg / 100 kg per point

Spring isolator typeOpen-coil steel spring

Natural frequency8 – 12 Hz (typical)

Vibration isolation85 – 95% (above 25 Hz)

Cable1.5 mm / 2 mm 7×7 stainless steel

AdjusterGripper-lock, push-button release

Anchor plate60×60 mm galvanized steel

Eye-boltM6 zinc plated / stainless option

Hanging lengthAdjustable 0.5 – 3.0 m

Fire class (steel)A1 (non-combustible)

OriginImported · stocked in KSA

WHY CHOOSE THIS

Why Use a Spring-Isolated Kit

Real isolation

A rigid hanger transmits every vibration straight to your ceiling slab. A spring isolator absorbs it. The difference is audible.

Adjustable

Gripper-lock cables let you raise or lower the hung element by hand — no tools.

Code compliant

Working load is 1/3 of breaking load (safety factor 3:1). Meets local civil-defense and ANSI/SDI standards.

Clean look

Slim cables and small anchor plate disappear visually against most ceilings.

FAQ

Frequently Asked Questions

Why not just use a rigid threaded rod?

Threaded rods are cheaper, but they're a direct mechanical connection — every vibration in the structure transmits straight to whatever you hung. For acoustic projects, that defeats the purpose. The spring isolator is what makes the hanging element actually quiet.

How many points per panel?

Standard rule: 1 m² needs 2 points minimum, 2 m² needs 3 points, then add 1 point per additional m². Cross-check against the static load of the kit.

Can I install one myself or do I need a contractor?

Most cable hangers are designed to be installed by one person with a drill and a ladder. For heavy loads or high ceilings (>4 m) we recommend our installer service.

Will the springs last?

Yes — they're coil springs rated for >1,000,000 fatigue cycles at design load. The cable is the lifetime-limiting element in normal use (~15 years indoors).

Fire-rated?

Steel parts are A1 (non-combustible). The kit can be used in any fire-rated ceiling assembly. For specific fire-resistance ratings of the assembled system, request the project drawing pack.
